Type Gear unit size
140 160 180 200 225 250 280 320 360 400 450 500 560 630 710
KDLS - - - 385 520 665 875 1220 1610 2270 3035 4400 5905 8005 10905
KDAS - - - 410 555 710 935 1300 1720 2450 3220 4620 6300 8600 11600
KDOS - - - 385 520 665 875 1220 1610 2270 3035 4400 5905 8005 10905
KDDS - - - 385 520 665 875 1220 1610 2270 3035 4400 5905 8005 10905
B.5 Enveloping surface sound pressure level
The gear unit complies with a sound power level, which places it in a gear unit type class
defined in VDI 2159, which is applied to produce the 80 % characteristic curve of the emission
characteristic map.
Adherence to limit values can, under specified Flender test conditions, be assumed with
statistical certainty.
Technical data
B.5 Enveloping surface sound pressure level
REDUREX Gear unit 5200en
Operating Instructions 03/2019 121
