Further information
You can find additional information on the water-oil cooler in the water-oil cooler unit operating
instructions, provided in the complete gear unit documentation.
Note
Observe the information provided in chapter of the Mounted oil supply system with water-oil
cooler (Page 32).
5.7.5 Installing a separate oil supply system
Procedure
To connect the oil supply system to the gear unit, proceed as follows:
1. Before connecting the system, remove the sealing sleeves from the suction and discharge
lines.
2. Mount the system on the gear unit in accordance with the dimension drawings in the
complete documentation, or install it as a separate system.
3. Avoid distorting the piping when installing.
Further information
Further information about the oil supply system can be found in the oil supply system operating
instructions in the complete documentation for the gear unit.
5.7.6 Electrical connections
Procedure
DANGER
Electric shock
Live parts can cause electric shock.
Ensure that the entire plant is de-energised before starting electrical installation work.
Carefully observe the five safety rules (Page 13).
To connect the motors and monitoring devices, proceed as follows:
1. Ensure that the connections of the motors and monitoring devices are not damaged.
2. Connect the motors and monitoring devices according to the terminal diagram.
Mounting
5.7 Connecting components
REDUREX Gear unit 5200en
Operating Instructions 03/2019 75
