3.4 Gear unit oil supply
Introduction
The oil supply to the various gear unit components can be implemented using the following oil
supply variants:
● Splash lubrication
● Pressure lubrication
● Combination of both oil supply variants
3.4.1 Splash lubrication
Unless otherwise agreed by contract, the gearing and rolling-contact bearings are supplied with
an adequate quantity of oil by splash lubrication.
3.4.2 Pressure lubrication
For special application conditions, depending on the order specification, splash lubrication can
be supplemented or replaced by oil pressure lubrication.
For specific individual applications, a motor pump can be used instead of a flange pump.
Designs
The following designs are possible:
● Mounted oil supply system
● Separate oil supply system
Note
All of the monitoring devices must be connected up and be functioning before commissioning.
Further information
Additional information and a detailed illustrated description of the gear unit and the oil supply
system can be found in the dimension drawing in the complete gear unit documentation.
Additional information about the oil supply system can be found in the separate data sheet, in
the list of equipment and in the oil supply system operating instructions provided in the
complete gear unit documentation.
