Points labelled on the gear unit Symbol Coloured markings
Alignment surface, horizontal
Alignment surface, vertical
These symbols indicate the oil level check‐
ing procedure using the oil dipstick.
These symbols indicate that the oil dip‐
stick must be firmly screwed in.
2.4 General warnings and symbols
The following table contains general warnings and their associated symbols.
Table 2-2 General warnings
ISO ANSI Warning
Warning - hazardous electrical voltage
Warning - explosive substances
--- Warning - entanglement hazard
--- Warning - hot surfaces
--- Warning - substances that can irritate or which are hazardous to health
--- Warning - caustic substances
--- Warning - suspended load
--- Warning - hand injuries
ATEX certification
Safety instructions
2.4 General warnings and symbols
REDUREX Gear unit 5200en
Operating Instructions 03/2019 15
