If couplings from other manufacturers are to be used, then, specifying the radial loads that
occur, ask the manufacturer which alignment errors are permissible.
5.7 Connecting components
5.7.1 Gear units with mounted components
Depending on the order specification, the gear unit can be equipped with various components.
Connect the closed-loop control and open-loop control electrical devices corresponding to the
specifications of the device supplier.
Further information
You can find additional information on operation and maintenance in the associated operating
instructions, provided in the complete gear unit documentation.
You can find the technical data of the mounted components in the contract-list of equipment
provided in the complete gear unit documentation.
5.7.2 Connecting the cooling coil
Procedure
To connect the cooling coil to the gear unit, proceed as follows:
1. Before connecting the cooling coil, remove the sealing plugs from the connection sleeves.
2. Flush through the cooling coil to remove any dirt or dust.
3. Connect up the cooling water inlet and drain lines. Refer to the dimension drawing for the
position of the connections.
Further information
Further information about the cooling coil can be found in the complete documentation for the
gear unit.
Note
Observe the information provided in chapter Cooling coils (Page 29).
