5.7.3 Connecting the air‐oil cooler
Procedure
To connect the air-oil cooler to the gear unit, proceed as follows:
1. Electrically connect the pressure monitor.
2. Electrically connect the fan motor.
3. Electrically connect the contamination indicator of the double change-over filter (if present).
Further information
You can find additional information on the water-oil cooler in the water-oil cooler unit operating
instructions, provided in the complete gear unit documentation.
Note
Observe the information provided in chapter of the Mounted oil supply system with air-oil cooler
(Page 30).
5.7.4 Connecting the water-oil cooler
NOTICE
Damage to the water-oil cooler
When installing the piping, it is not permissible that the connections of the water-oil cooler are
subject to force, torque or vibration.
Procedure
To connect the water-oil cooler to the gear unit, proceed as follows:
1. Remove the connecting bushes from the cooling water connection before connecting the
water-oil cooler.
2. Flush the water-oil cooler to remove any dirt and pollution.
3. Connect up the cooling water inlet and drain lines. Refer to the dimension drawing for the
direction of flow and the position of the connections.
4. Electrically connect the pressure monitor (only for appropriately equipped gear units).
Mounting
5.7 Connecting components
REDUREX Gear unit 5200en
74 Operating Instructions 03/2019
