15 Settings FLUXUS F808, F809
UMFLUXUS_F808_8091V1-2-1EN, 2019-08-23 139
15.2.2 Fluid pressure
The dependence of the fluid parameters on the pressure can be taken into account.
15.2.3 Measuring point number
15.2.4 Transducer distance
15.2.5 Error value delay
The error value delay is the time after which an error value will be sent to an output if no valid measured values are avail-
able.
15.2.6 Alarm state indication
During the next scroll through the program branch Parameter, the outer pipe diameter
that corresponds to the entered pipe circumference will be displayed.
example: 180 mm : π = 57.3 mm
Note! The pipe circumference is only edited temporarily. When the transmitter switches back to the display
of the pipe circumference (internal recalculation), slight rounding errors may occur.
example: entered pipe circumference: 100 mm
displayed outer pipe diameter: 31.8 mm
When the transmitter switches back to the display of the pipe circumference, 99.9 mm will be dis-
played.
If on has been selected, the fluid pressure will be requested in the program branch Param-
eter.
If off has been selected, 1 bar will be used for all calculations.
Note! For documentation purposes, it is useful to enter the fluid pressure, even if the transmitter contains
no pressure-dependent characteristic curves.
Select
(1234)
if the measuring point is to be identified only by numbers, point and hyphen.
Select (↑↓←
→) if the measuring point is to be designated with ASCII characters.
recommended setting: user
• user will be selected if the measuring point is always the same
• auto can be selected if the measuring point changes often
In the program branch Measuring, the recommended transducer distance will be dis-
played in parentheses, followed by the entered transducer distance if the recommended
and the entered transducer distances are not identical.
During transducer positioning in the program branch Measuring
• only the entered transducer distance will be displayed if Transd. Distance = user
has been selected and the recommended and the entered transducer distances are iden-
tical,
• only the recommended transducer distance will be displayed if Transd. Distance =
auto has been selected.
Select edit to enter an error value delay. Select damping if the damping factor is to be
used as the error value delay.
For further information on the behavior in case of missing measured values see section
17.1.2 and 17.2.
Select on to display the alarm state during the measurement.
Fur further information on the alarm outputs see section 17.6.
Outer Diameter
57.3 mm
Fluid pressure
off >ON<
Meas.Point No.:
(1234) >(↑↓← →)<
Transd. Distance
auto >USER<
Transd. Distance?
(50.8) 50.0 mm
Transd. Distance?
50.8 mm
Error-val. delay
damping >EDIT<
SHOW RELAIS STAT
off >ON<
