8. 3x Digital inputs (ON-OFF or pulsed S0)
9. 3x RS485/RS422 ports
10. SIM card holder
11. Modem SMA antenna connector
12. USB port (for extension)
13. RESET button
1.4 Supported Devices
The WebdynSunPM is compatible with all devices that include one of the supported protocols.
Partial list of the supported protocols:
INVERTER PROTOCOL PHYSICAL INTERFACE SPECIFICATIONS
SMA-net RS485/RS422 2 wires 100 max
Modbus TCP Ethernet 254 max
Modbus RTU RS485/RS422 2 wires or 4 wires 247 max
Power-One Aurora RS485/RS422 2 wires 100 max
TIC USB (cable optional) 1 max
Delta-Solivia RS485/RS422 2 wires 100 max
Currently, much inverter equipment runs using Modbus. The concentrator accepts all Modbus
RTU and TCP devices.
1.5 Product References
Product:
REFERENCES DESCRIPTIONS
WG0517-A01 WebdynSunPM (Europe and India version)
WG0517-A02 WebdynSunPM (Monde version)
WG0517-A03-DEIE WebdynSunPM in DEIE box (Europe and India version)
