■ Point to Continuous adjust and press the joystick to put the camera in automatic
mode, continuously optimizing the image for best level and span
For more information about the Level/Span command, see section 10.2.4.3 – Lev-
el/Span on page 89.
10.2.4.5 Palette
10392003;a4
Figure 10.37 Palette dialog box
Point to Palette and press the joystick to display a dialog box where you can change
the color palette.
Figure 10.38 Explanations of the Palette dialog box
CommentsValueLabel
Move the joystick left/right to change the palette.Configuration-depen-
dent
Palette
Move the joystick left/right to reverse the current
palette.
■
Yes
■
No
Inverted
Custom palettes (*.pal) can be used by the camera. For more information about how
to create custom palettes, contact FLIR Systems.
10.2.4.6 Hide graphics
Point to Hide graphics and press the joystick to hide all on-screen graphics (e.g. result
table, status bar etc.). To display the graphics again, press the joystick or the C button.
10
90 Publ. No. 1557966 Rev. a155 – ENGLISH (EN) – February 6, 2006
10 – Camera program
