ActionStep
Point to Add circle on the Analysis menu and press the joystick. A circle will now
appear on the screen. The measured temperature will be displayed in the result
table in the top right corner of the screen.
You are now in edit mode and can move the circle in any direction by pressing
and moving the joystick. To leave the edit mode, press the C button twice. You
can also leave the edit mode by holding down the joystick for a few seconds,
which will display a shortcut menu.
2
For more information about circles, see section 10.2.3.4 – Add circle on page 81.
8.3.4 Laying out & moving a line
ActionStep
Press the joystick to display the horizontal menu bar.1
Point to Add line on the Analysis menu and press the joystick. A line will now ap-
pear on the screen. The measured temperature will be displayed in the result table
in the top right corner of the screen.
You are now in edit mode and can move the line in any direction by pressing and
moving the joystick. To leave the edit mode, press the C button twice. You can
also leave the edit mode by holding down the joystick for a few seconds, which
will display a shortcut menu.
2
For more information about lines, see section 10.2.3.5 – Add line on page 83.
8.3.5 Creating & changing an isotherm
ActionStep
Press the joystick to display the horizontal menu bar.1
Point to Add isotherm on the Analysis menu and press the joystick. An isotherm
will now be added to your image. The isotherm levels will be displayed in the result
table in the top right corner of the screen.
You are now in edit mode and can change the isotherm levels by moving the joy-
stick up/down. To leave the edit mode, press the C button twice. You can also
leave the edit mode by holding down the joystick for a few seconds, which will
display a shortcut menu.
2
For more information about creating & changing an isotherm, see section 10.2.3.6 –
Add isotherm on page 85.
8.3.6 Resizing a measurement marker
➲ This example procedure, which applies to all types of measurement markers, as-
sumes that you have laid out only one measurement box on the screen and exited
the menu system.
8
Publ. No. 1557966 Rev. a155 – ENGLISH (EN) – February 6, 2006 45
8 – Tutorials
