ActionStep
Press the joystick to display the horizontal menu bar.1
Point to Edit mode on the Analysis menu and press the joystick. This will display
eight gray handles on the box.
2
Press the joystick once again. This will make a small box in the middle turn yellow.3
Move the joystick left/right or up/down to select one of the yellow handles.4
Press the joystick once again. This will make the yellow handle turn blue.5
To resize the box, move the joystick any direction, then press the joystick again
to confirm the size.
6
Press the C button once to leave the edit mode.7
8.3.7 Moving a measurement marker
➲ This example procedure, which applies to all types of measurement markers, as-
sumes that you have laid out only one measurement box on the screen and exited
the menu system.
ActionStep
Press the joystick to display the horizontal menu bar.1
Point to Edit mode on the Analysis menu and press the joystick. This will display
eight gray handles on the box.
2
Press the joystick once again. This will make a small box in the middle turn yellow.3
Press the joystick once again. This will make the small box turn blue.4
To move the box, move the joystick any direction.5
Press the C button three times to leave the edit mode.6
8
46 Publ. No. 1557966 Rev. a155 – ENGLISH (EN) – February 6, 2006
8 – Tutorials
