10.2.3 Analysis menu
10.2.3.1 Edit mode
Point to Edit mode and press the joystick to enter the edit mode of the camera. When
the camera is in edit mode you can select, move, and resize measurement markers
as well as changing levels of isotherms etc. You leave edit mode by pressing the C
button.
10.2.3.2 Add spot
Point to Add spot and press the joystick to add a spot. A spot will now be displayed
on the screen. Press and hold down the joystick for one second when the spot is
selected to display a shortcut menu.
10390103;a3
Figure 10.13 Shortcut menu for Spot
Figure 10.14 Explanations of the shortcut menu for Spot
ExplanationCommand
Point to Delete and press the joystick to delete the spot.Delete
Point to Exit edit mode and press the joystick to exit the edit mode.Exit edit mode
Point to Set as ref temp and press the joystick to use the spot tem-
perature as the reference temperature.
Set as ref temp
See below.Settings
Point to Settings and press the joystick to display a Spot settings dialog box where
you can change the settings for the spot.
10
Publ. No. 1557966 Rev. a155 – ENGLISH (EN) – February 6, 2006 77
10 – Camera program
