FLIR ThermaCAM P45

6.2 Rear connectors
10438703;a2
Figure 6.3 How to connect system components: Rear connectors
Figure 6.4 Explanations of callouts
ExplanationCallout
S-Video cable1
CompactFlash card2
Power supply cable3
CVBS cable (i.e. composite video)4
Remote control cable5
6
