ActionStep
Do one of the following:
■
Press and hold down the S button for a few seconds to save the image
■
Point to Save on the File menu and press the joystick
3
For more information about saving images, see section 10.2.2.2 – Save on page 74.
8.3 Working with measurements
8.3.1 Laying out & moving a spot
ActionStep
Press the joystick to display the horizontal menu bar.1
Point to Add spot on the Analysis menu and press the joystick. A spot will now
appear on the screen. The measured temperature will be displayed in the result
table in the top right corner of the screen.
You are now in edit mode and can move the spot in any direction by pressing and
moving the joystick. To leave the edit mode, press the C button twice. You can
also leave the edit mode by holding down the joystick for a few seconds, which
will display a shortcut menu.
2
For more information about spots, see section 10.2.3.2 – Add spot on page 77.
8.3.2 Laying out & moving an box
ActionStep
Press the joystick to display the horizontal menu bar.1
Point to Add box on the Analysis menu and press the joystick. A box will now
appear on the screen. The measured temperature will be displayed in the result
table in the top right corner of the screen.
You are now in edit mode and can move the box in any direction by pressing and
moving the joystick. To leave the edit mode, press the C button twice. You can
also leave the edit mode by holding down the joystick for a few seconds, which
will display a shortcut menu.
2
For more information about boxes, see section 10.2.3.3 – Add box on page 79.
8.3.3 Laying out & moving a circle
ActionStep
Press the joystick to display the horizontal menu bar.1
8
44 Publ. No. 1557966 Rev. a155 – ENGLISH (EN) – February 6, 2006
8 – Tutorials
