Figure 16.23 Horizontal, vertical and instantaneous fields of view for certain distances to targets. 9 mm
lens / camera type 253.
Figure 16.24 F-number and close focus limits for various lenses
9.0 mm18 mm36 mm72 mm124 mmLens →
0.150.10.31.24Close focus limit (m)
0.490.320.983.9313.11Close focus limit (ft.)
1.01.01.01.01.0f-number
16
Publ. No. 1557966 Rev. a155 – ENGLISH (EN) – February 6, 2006 135
16 – Technical specifications & dimensional drawings
