Figure 9.3 Camera parts, 3
Description of partCallout
Cover for additional connectors1
Joystick
For more information about the joystick, see section 9.2 – Keypad buttons &
functions on page 64.
2
ON/OFF button (green)
For more information about the ON/OFF button, see section 9.2 – Keypad buttons
& functions on page 64.
3
Not implemented.4
9
Publ. No. 1557966 Rev. a155 – ENGLISH (EN) – February 6, 2006 61
9 – Camera overview
