Flowserve MX User Manual

Limitorque
®
MX Electronic Actuator FCD LMENIM2306-09-AQ – 08/17
105
flowserve.com
Applicable Emissions standards EN61000-6-4:2007+A1:2011 Industrial Environments - Class A - Test Limits & Levels
Radiated emissions
EN55011:2009+A1:2010 (CISPR11)
330 MHz to 230 MHz
230 MHz to 1 GHz
40 dB (μV/m)
47 dB (μV/m)
FCC Part 15, (CFR47 Part 15.109
30 MHz to 88 MHz
88 MHz to 216 MHz
216 MHz to 960 MHz
> 960 MHz
90 dB (μV/m)
150 dB (μV/m)
210 dB (μV/m)
300 dB (μV/m)
Conducted emissions
EN55011:2009+A1:2010 (CISPR11)
150 kHz to 500 kHz
500 kHz to 30 MHz
79 dB (μV) (quasi-pk), 66 dB (μV) (avg)
73 dB (μV) (quasi-pk), 60 dB (μV) (avg)
FCC Part 15, (CFR47 Part 15.107)
Applicable immunity standards EN61000-6-2:2005 (Perf. Criteron) Industrial Environments - Test Limits & Levels
ESD IEC61000-4-2 (B)
Air: AC, DC, Signal
Contact: AC, DC, Signal
±2 kV, ±4 kV, ±8 kV
±1 kV, ±2 kV, ±4 kV
Radiated RF immunity IEC61000-4-3 (A)
Enclosure @ 80 MHz to 1 GHz 10 Vrms/m @ 80% AM, 1 kHz
Enclosure @ 1 GHz to 2.7 GHz 3 Vrms/m @ 80% AM, 1 kHz
Fast transients/burst IEC61000-4-4 (B) AC, Signal ±2 kV, ±1 kV
Voltage surges IEC61000-4-5 (B)
Common: AC, Signal
Differential: AC, Signal
±2 kV, ±l kV
±l kV, ±l kV
Conducted RF immunity IEC61000-4-6 (A) AC @ 150 kHz to 80 MHz 10 Vrms @ 80% AM, 1 kHz
Magnetic field immunity IEC61000-4-8 (A) Three mounting axis 30A/m
Voltage dips and interrupts
IEC61000-4-11 (B) 3 dips, 10 sec apart
> 95% dip for 1 cycle @ 50/60 Hz
30% dip for 500 ms @ 50/60 Hz
60% dip for 200 ms @ 50/60 Hz
IEC61000-4-11 (C) 3 dips, 10 sec apart > 95% interrupt for 5 sec @ 50/60 Hz
EMC - standards to which the single phase ACV MX actuator complies:
Applicable Emissions standards EN61326-1 (CISPR11) Industrial Environments - Class A - Test Limits & Levels
Radiated emissions
EN55011:2009+A1:2010 (CISPR11
330 MHz to 230 MHz
230 MHz to 1 GHz
40 dB (μV/m)
47 dB (μV/m)
FCC Part 15, (CFR47 Part 15.109)
30 MHz to 88 MHz
88 MHz to 216 MHz
216 MHz to 960 MHz
> 960 MHz
90 dB (μV/m)
150 dB (μV/m)
210 dB (μV/m)
300 dB (μV/m)
Conducted emissions
EN55011:2009+A1:2010 (CISPR11)
150 kHz to 500 kHz
500 kHz to 30 MHz
79 dB (μV) (quasi-pk), 66 dB (μV) (avg)
73 dB (μV) (quasi-pk), 60 dB (μV) (avg)
FCC Part 15, (CFR47 Part 15.107)
Applicable immunity standards EN61326-1 (Performance Criterion) Industrial Environments - Test Limits & Levels
Electrostatic Discharge EN61000-4-2 (B)
Contact
Air
±1 kV, ±2 kV, ±4 kV
±2 kV, ±4 kV, ±6kV, ±8 kV
Radiated RF Susceptibility EN61000-4-3 (A)
Enclosure @ 80 MHz to 1 GHz
Enclosure @ 1.4 GHz to 2 GHz
Enclosure @ 2 GHz to 2.7 GHz
10 Vrms/m @ 80% AM, 1 kHz
3 Vrms/m @ 80% AM, 1 kHz
1 Vrms/m @ 80% AM, 1 kHz
Electrical Fast Transient/Burst EN61000-4-4 (B)
AC Power, DC Power
I/O (mains connected)
I/O (non-mains)
±2 kV
±2 kV
±1 kV
Voltage surges EN61000-4-5 (B)
AC Power, DC Power
I/O (mains connected)
I/O (non-mains)
±1 kV (DM), ±2 kV (CM)
±2 kV (CM)
±1 kV (CM)
Conducted RF Immunity EN61000-4-6 (A)
AC Power, DC Power, I/O
@ 150 kHz to 80 MHz
30 A/m, 60 sec dwell
Magnetic Immunity EN61000-4-8 (A) Three mounting axis, X, Y, Z 30 A/m, 60 sec dwell
Voltage Dips and Interrupts
EN61000-4-11 (B)
3 dips, 10 sec apart
3 dips, 10 sec apart
3 dips, 10 sec apart
100% dip for 1 cycle @ 50/60 Hz
60% dip for 200 ms @ 50/60 Hz
30% dip for 500 ms @ 50/60 Hz
EN61000-4-11 (C) 3 dips, 10 sec apart 100% interrupt for 5 sec @ 50/60 Hz
Table 7.1 – EMC – Electromagnetic Compatibility (EMC) and Electromagnetic Interference (EMI) standards to which the three
phase ACV MX actuator complies:
