Flowserve MX User Manual

Limitorque
®
MX Electronic Actuator FCD LMENIM2306-09-AQ – 08/17
2
Contents
1 Important Notes 8
2 Quick Start 10
2.1 Calibrate – Position Limits 11
2.1.1 Entering the Setup Mode 11
2.1.2 Electrical Operation Feature 11
2.1.3 Handwheel Operation Feature 12
2.2 DDC/Modbus Option 14
2.3 Check the Settings 14
3 Installation and Operation 15
3.1 Preparing the Stem Nut 15
3.1.1 Type “B” Bases: Torque-only Applications 15
3.1.2 Type “A” Bases: Thrust-only Applications 17
3.1.3 Type “BL” Drive: Splined Drive Application 21
3.2 Mechanical Installation Onto Valve or Gearbox 21
3.2.1 Mounting (Type “B” Bases): Torque-only 22
3.2.2 Removal (Type “B” Bases): Torque-only 22
3.2.3 Mounting (Type “A” Bases): Thrust-only 22
3.2.4 Removal (Type “A” Bases): Thrust-only 22
3.3 Electrical Connections 23
3.3.1 Removing Terminal Cover 23
3.3.2 Terminal Compartment Documents 23
3.3.3 Sealing Cable/Conduit Entries 23
3.3.4 Recommended Terminal Connections 23
3.3.5 Termination of Cables 25
3.3.6 Cable Connections 25
3.3.7 Network Installations 25
3.3.8 Foundation Fieldbus Installation 29
3.3.9 Network Wiring – Profibus DP/PA Installation 30
3.3.10 Network Wiring – DeviceNet 30
3.3.11 HART Installation 31
3.3.12 Replacing Terminal Cover 31
3.3.13 External Earth/Ground Connections 31
3.4 Terminal Block Shield Installation 31
3.5 Commissioning the Actuator 31
3.5.1 Default Configuration Set 32
3.5.2 View the Existing Settings 33
3.5.3 Entering the Setup Mode 33
3.5.4 Setting Position Limits 34
3.6 Operating the MX Actuator 37
3.6.1 Manual Operation 37
3.6.2 Electrical Operation 37
3.6.3 Local Control 37
3.6.4 Remote Control 38
3.6.5 Local Indication 38
4 Customizing the Actuator 39
4.1 Changing the Existing Settings 39
4.2 Password Entry 42
4.3 New Password 42
4.4 Valve Setup 43
LMENIM2306-09 AQ.indd 2 Mittwoch23.08.17 08:53

Flowserve MX Specifications

General

Brand	Flowserve
Model	MX
Category	Controller
Language	English
