7.3 Single-Phase MX Full Load Amperage Values (FLA)
The product nameplate lists Full Load Amperage values at 40°C. The Full Load Amperage values vary with temperature.
The change in FLA over temperature is shown in the tables below.
MX-05 20% run load FLA@100/240 VAC
RPM 15/18 22/26 33 /40 43/52 65/77 84/100 127/155 165/200
+70°C 2.7/1.6 3.3/1.9 4.4/2.5 5.6/3.0 6.3/3.5 5.9/3.2 8.5/4.6 8.8/4.6
+25°C & +40°C 2.8/1.8 3.6/2.1 5.0/2.8 6.3/3.4 7.8/4.2 7.7/4.0 11/6 11.3/6
-30°C & -40°C 6.8/3.7 8.6/4.5 11.2/5.8 13.6/7.2 11.1/6.3 13.7/7 18/9.3 20/10
MX-10 20% run load FLA@100/240 VAC
RPM 15/18 22/26 33 /40 43/52 65/77 84/100 127/155 165/200
+70°C 4.5/2.6 5.9/3.4 8/4.6 9.9/5.6 11.7/6.7 11.5/6.1 15.5/9 15.8/9
+25°C & +40°C 5/2.9 6.6/3.7 9.5/5.3 12/6.7 13.2/7.5 13.1/7.3 18/11 19/11
-30°C & -40°C 9.1/4.9 11.7/6.4 16.3/9 20.2/11.2 18.7/10.6 18.4/10.6 26/15 30/18
Notes
1. -20°C/-30°C /-40 °C to +40°C values are the same value due to different gear lubrications being utilized
2. 40% run load FLA values are 1.5 times the 20% run load FLA values
3. When operating at 115 VAC reduce nameplate FLA@100 VAC by 6%
4. When operating at 230 VAC increase nameplate FLA @240 VAC by 8%
5. When operating at 208 VAC increase nameplate FLA @240 VAC by 27%
