E119-P
FW_E119-P_M_v0301-02_EN Page 65
C.2 RUNTIME VARIABLES OF THE UNIT
When reading runtime variables, the given value may differ slightly from the value that is displayed
on the display – this is because the display is limited in the number of digits and may have a slower
update rate.
When variables are read in integer format, the returned values are given including the decimals. For
example, when two decimals are selected for total, and total has a value of 123456,78 the display
will show 23456,78 while communication will read a “total” of 12345678 (note that the decimals
should be adapted according to the setting in “total decimals”, in this case 2).
RUNTIME VARIABLES OF THE E119-P - INTEGER BASED – INDIVIDUAL READ
PDU
ADDRESS
HOLDING
REGISTER
VARIABLE
NO. OF
REG’S
R/W TYPE VALUES / REPRESENTATION / REMARKS
[d] 255
[h] 0x00FF
40256 battery status 1 R uint16 0 = unknown
1 = normal
2 = low battery
[d] 516
[h] 0x0204
40517 error status
(bitfield)
1 R uint16 [d] 0 = no error
[d] 1 = display error
[d] 2 = data-storage error
[d] 4 = initialization error
[d] 16 = IO configuration error base
[d] 32 = IO configuration error interface
[d] 64 = Linearization error (M-factor out of range)
[d] 128 = Automatic K-factor conversion error
[d] 560
[h] 0x0230
40561 accumulated
total
3 R uint48 0.000…99999999999999
Representation: unit, decimals depending on variables 32, 33
[d] 566
[h] 0x0236
40567 total 3 R * uint48 0.000…9999999999
Representation: unit, decimals depending on variables 32, 33
[d] 572
[h] 0x023C
40573 flowrate 2 R uint32 0.000…9999999
Representation: unit, time, decimals depending on variables
48, 49, 50
[d] 4640
[h] 0x1220
44641 Total command
register
1 R/W uint16 Commands:
0x0102 (258): Clear total
* Clearing total: Total can be cleared by writing the correct command to the total command register, as shown above.
It is also still possible to use the old method: Write a value of 0 to all the 3 registers of total in a single write
action. Writing any other value will result in the reply of an error message.
Note: The runtime variables shown in above list must always be read or written individually, for the indicated
number of registers, in 1 single action!
RUNTIME VARIABLES OF THE E119-P - INTEGER BASED – CONTIGUOUS READ
PDU
ADDRESS
HOLDING
REGISTER
VARIABLE
NO. OF
REG’S
R/W TYPE VALUES / REPRESENTATION / REMARKS
[d] 6146
[h] 0x1802
46147 total 4 R uint64 0.000…9999999999
Representation: unit, decimals depending on variables 32, 33
[d] 6150
[h] 0x1806
46151 accumulated
total
4 R uint64 0.000…99999999999999
Representation: unit, decimals depending on variables 32, 33
[d] 6154
[h] 0x180A
46155 flow rate 2 R uint32 0.000…9999999
Representation: unit, time, decimals depending on variables
48, 49, 50
[d] 6156
[h] 0x180C
46157 current day total 4 R uint64 0.000…9999999999
Representation: unit, decimals depending on variables 32, 33
[d] 6160
[h] 0x1810
46161 previous day
total
4 R uint64 0.000…9999999999
Representation: unit, decimals depending on variables 32, 33
Note: The list of runtime variables shown above can be read as one contiguous list of registers. Unused registers return 0.
RUNTIME VARIABLES OF THE E119-P - FLOATING POINT BASED 32 BIT – CONTIGUOUS READ
PDU
ADDRESS
HOLDING
REGISTER
VARIABLE
NO. OF
REG’S
R/W TYPE VALUES / REPRESENTATION / REMARKS
[d] 6402
[h] 0x1902
46403 total 2 R float32 0... 9999999
Representation: unit depending on variable 32
[d] 6404
[h] 0x1904
46405 accumulated
total
2 R float32 0... 99999999999
Representation: unit depending on variable 32
