E018-P
Page 30 FW_E018-P_M_v0302-02_EN
10 OTHERS
10.3 SERIAL NUMBER
Provides important information on your unit. This information may be
required for maintenance, support and upgrade purposes.
10.4 PASSWORD
All SETUP values can be password protected.
A four-digit password can be programed, for example 1234.
To disable password protection, enter four zeros (0000).
10.5 KEY LOCK
To prevent misuse of the optical keyboard it can be locked automatically
after 30 seconds by enabling this function.
In battery supplied applications, the backlight can come on each time the
keyboard is activated. As this can quickly degrade the battery, it is advised
to leave the keyboard lock function enabled so that the backlight only
comes on when an optical key is pressed for at least one second. The
keyboard lock function also uses less battery power.
10.6 TAG NUMBER
For identification of the unit and communication purposes, a unique tag
number of maximum seven digits can be entered.
