E119-P
Page 24 FW_E119-P_M_v0301-02_EN
7 ANALOG OUTPUT DEFAULT
7.1 OUTPUT
enable, disable disable
7.2 RATE MIN (4MA)
0.000 - 9999999 0
7.3 RATE MAX (20MA)
0.000 - 9999999 99999
7.4 FILTER
01 - 99 (01 = off) 01
7.5 CUT-OFF
0.0 - 9.9 % 0.0 %
7.6 TUNE MIN (4MA)
0000 - 9999 -
7.7 TUNE MAX (20MA)
0000 - 9999 -
8 PULSE OUTPUT DEFAULT
8.1 MODE
disable, scaled, retransmit disable
8.2 WIDTH
0.000 - 9.999 sec (0.000 = off) 0.000
8.3 AMOUNT
0000.000 - 9999999 per pulse 1000
9 COMMUNICATION DEFAULT
9.1 MODE
off, bus asc, bus rtu, printer printer
9.2 SPEED
1200, 2400, 4800, 9600, 9600HP, 19200, 38400, 57600 9600
9.3 DATABITS
8 bits, 7 bits 8 bits
9.4 PARITY
none, even, odd none
9.5 ADDRESS
001 - 247 1
9.6 TRANSMIT DELAY
0.000 - 0.255 sec 0.015 sec
9.7 LINE DELAY
0.00 - 2.55 sec 0.00 sec
9.8 LINE TERMINATION
CR/LF, CR, LF CR/LF
9.9 START ROW
0 - 9 (empty lines) 2
9.A END ROW
0 - 9 (empty lines) 4
9.B FORM FEED
disable, enable disable
9.C DATE FORMAT
YY/MM/DD, DD/MM/YY, MM/DD/YY YY/MM/DD
10 TICKET DEFAULT
10.1 HEADER 1
16 ASCII characters (use configuration tool for all options) Fluidwell
10.2 HEADER 2
16 ASCII characters (use configuration tool for all options)
10.3 HEADER 3
16 ASCII characters (use configuration tool for all options)
10.4 HEADER 4
16 ASCII characters (use configuration tool for all options)
10.5 TICKET NUMBER
0000001 - 9999999 1
10.6 AUTO PRINT
disable, on contract hour disable
10.7 DAILY TOTAL
no print, print (on totalizer ticket) print
10.8 DELIVERY MODE
disable, enable disable
10.9 DELIVERY NUMBER
0000001 - 9999999 1
10.A ACC. TOTAL
no print, print (on delivery ticket) print
11 OTHERS DEFAULT
11.1 MODEL
- -
11.2 SOFTWARE VERSION
xx.xx.xx -
11.3 SERIAL NUMBER
xxxxxxx -
11.4 TIME
00:00:00 - 23:59:59 (hh.mm.ss) 00:00:00
11.5 DATE
00.01.01 - 99.12.31 (yy.mm.dd) 22.01.01
11.6 PASSWORD
0000 - 9999 (0000 = off) 0000
11.7 KEY LOCK
enable, disable enable
11.8 TAG NUMBER
0000000 - 9999999 0000000
