Fluke 5730A User Manual

Front-Panel Operation
Set up the Calibrator 4
4-49
There are selections without a submenu listed beneath them that are used to start
processes. For example, the Run DC Zero selection from the Calibration menu starts the
DC Zero process (see Chapter 7).
Exit
Calibration
Run DC Zero 3/04/2013
Run Artifact Cal 3/04/2013
Setup Menu
Run Calibration Check
Run Wb Gain Cal 8/29/2013
Run Wb Flatness Cal 8/29/2013
Change Calibration Passcode Temperature ˚C 23.0
Restore Factory Defaults
Generate Report
Calibration Shifts
Check Shifts
Raw Data
Range Adjustment
DC
AC
Resistance
hhp173.eps
There are several types of selections that are used for settings. In general, these selections
show what is being set in white, and the value that it is currently set to is in amber. See
the Temperature °C selection in the screen above.
Touchscreen selections with two possible values look like the Confidence Level
selection shown in the screen below. Touch Confidence Level to change the value from
99% to 95%. Touch it again to change the value back to 99%.
Calibration Interval 1 Year
Confidence Level
Instrument
Setup
Uncertainty
Information
Setup Menu
Exit
99%
hhp107.eps

Fluke 5730A Specifications

General

Type	Multifunction Calibrator
Resistance Range	0 to 1 GΩ
AC Voltage Frequency	10 Hz to 1 MHz
Display	Color LCD
Interfaces	RS-232, Ethernet
Weight	18 kg
DC Voltage Range	0 to ±1100 V
Dimensions	172 mm H x 432 mm W x 457 mm D (6.8 in H x 17 in W x 18 in D)
