THEORY
OF
OPERATION
is
stored
in
the VCO
Calibration
EPROM
on the
Controller
board. For
output
frequencies
above
512 MHz
and below 245 MHz,
the KV DAC
setting
is halved
to
account
for the
effective frequency
doubling that occurs
on these bands.
Range
switching
is provided by
resistors R77, R7S,
R79, and FETs QIO,
Qll, and Q12.
Comparator U42
converts TTL
levels to OV (on), and
-15V (off) required by
the FETs.
U41A
buffers
the range
switch, and in
conjunction with R82,
provides an
overall FM
adjustment.
At
this point,
the
audio signal
splits
into two paths. The
path that
connects to
the
integrator, U41,
is for
modulation frequencies
inside the loop
bandwidth.
The path
that
sums with
the VCO control
voltage at J103 is
for
frequencies
outside the
loop
bandwidth.
U41D
is an
active high-pass filter
that compensates
for the
non-ideal
integrator
and the
ac coupling to
the VCO tuning
port.
The
output
of U41D is
summed with
the VCO control voltage
via R88 and
Cl
17. FET
Q13
allows
the FM to be
turned off. The
audio
signal is also
processed by
integrator
U41A,
R85, R86,
and Cl 15.
The audio signal is
ac coupled into
the
phase-detector
integrator
via R89,
R90, Cl
16,
and FET
Q14.
(Resistor
R90 adjusts
the low
frequency
FM
gain). This
integrator
makes
the phase
modulation
produced at the
Phase
Detector
appear
as FM,
3-47. 800/40
MHz PLL
When the
Signal
Generator
is
operated
in the
low-band, the
800-MHz oscillator
is
locked
to the
10‘MHz
Reference
and
provides
a local
oscillator
for the
heterodyne
circuit
on
the
Output PCA. It
also provides
a 40-MHz
signal to
the
sub-synthesizer
clock
generator.
The
800-MHz
VCO
is connected
to the
divide-by-four,
U61, followed by
a
divide-by-five,
U62 and U63,
providing 40
MHz to
the sub-synthesizer
clock
generator
through
selector
U64.
When
the Signal
Generator is not
in the low-band, the
800-Hz
oscillator and
the first
divide-by-four
are
disabled
by turning
off
Q28
(HET),
The
40-MHz
Oscillator
consisting of U64, L66,
and CR24, is
selected by U64.
The 40-Hz
balanced ECL
signal from U64
drives the
two-phase clock
generator. A
self-biased
gate,
U65,
converts ECL
to TTL. U66
divides the40-MHz
signal by four to
produce a
lO-MHz
signal that
is
compared
against the
10-MHz reference in the
phase detector U59
and U65.
Op-amp U60,
resistor
network Z9,
and C181, C185, C186,
and C201
integrate the
phase
detector
pulses to
produce
a dc
control
voltage for the
800-MHz VCO
and the
40-MHz
VCO.
3-48. 800-MHz
VCO
The
800-MHz VCO
is
a low noise,
limited range,
voltage-controlled
oscillator for
the
800-
MHz PLL.
The basic
oscillator uses
two active devices
operating as
negative
resistance
elements,
coupled
symmetrically to a
resonator
made up of a
varactor and
an
adjustable
capacitor.
Each
device is
followed by an
amplifier and
isolation
pad. This
provides two
coherent outputs
of +5 dBm
to the PLL and 0
dBm to the
output
A2A4
assembly.
The
oscillator
transistors Q32
and
Q35
are biased at 13
mA
by RI82
and R191.
The
voltage
at the
collectors of Q32
and
Q35
is typically
+2.5V. The
two
6-dB
amplifiers
Q33
and
Q37
are biased so
that the voltage
at
their emitters is
about +0.3V,
and
the voltage
at
their bases is
about +IV
with
the collectors at
+6.5V.
The PLL
control
voltage
from U60 provides
the tuning
voltage
for the
varactor CR27.
The adjustable
capacitor C206
is set to provide
+16V on the
varactor to
optimize the
VCO
noise
characteristic. The
output attenuators
consisting of R
186,
R187, R189,
R197,
