OPTION
-651
LOW-RATE Fm
2. With the DMM, measure the dc
voltage
at A2A9 Ul-6. Adjust R4 for
OV
±
O.IV.
651-6.
LIST OF REPLACEABLE PARTS
Table
651-2
lists replaceable parts for the
6060A-651.
Figure
651-1
is
the component
location diagrams for the
6060A-651.
Table 651-1.
Low-Rate
FM DIP Switch
NORMAL
LOW-RATE FM
1. Closed Open
2. Open Closed
Z, Closed Open
4.
Closed
Open
5. Not Applicable Not Applicable
6- Open Closed
661-3
To Next Page
