Calibration Adjustment
Final Calibration For v11.10 and later 5
5-21
7. Press
F2
to select the next calibration step, set the 5502A to the next
calibration point, and start the calibration. Continue through all calibration
points of Table 5-5.
8. Set the 5502A to Standby, and continue at the Input Pos ABCD (AB)
Calibration section.
Table 5-5. Input AB Gain and Position Calibration Points
Cal step UUT input value (5502A SCOPE, MODE volt, SCOPE Z 1 MΩ, 1 kHz)
CL 0504 500 mV, 1 kHz, MODE VOLT
CL 0624 Open inputs, Calibrator STBY
CL 0673 50 V, 1 kHz, MODE volt
CL 0660 300 mV
CL 0604 500 mV
CL 0637 none (5500 standby)
CL 0504 500 mV
CL 0624 none (5500 standby)
CL 0599 10 mV
CL 0600 25 mV
CL 0601 50 mV
CL 0602 100 mV
CL 0622 none (5500 standby)
CL 0603 250 mV
CL 0662 2 V
CL 0605 1 V
CL 0606 2.5 V
CL 0607 5 V
CL 0664 20 V
CL 0608 10 V
CL 0609 25 V
CL 0610 50 V (set 5502A to OPR!)
