Fluke ScopeMeter 190 II Series Service Manual

Fluke 190-062, -102, -104, -202, -204, -502, -504
Service Manual
2-16
10:1 Probe VPS410
Accuracy
Probe accuracy when adjusted on the test tool:
DC to 20 kHz....................................................... ±1 %
20 kHz to 1 MHz ................................................. ±2 %
1 MHz to 25 MHz ................................................ ±3 %
For higher frequencies the probe’s roll-off starts affecting the accuracy.
For further probe specifications see the instruction sheet supplied with the VPS410 probe set.
Electromagnetic Immunity
The Fluke 190 Series II test tools, including standard accessories are compliant to EN 61326-1, with the addition of the
table that follows.
Scope Mode (10 ms/div: Waveform disturbance with VPS410 voltage probe shorted (see table below).
(E = 3V/m)
Frequency No Disturbance
Disturbance <10 % of
full scale
Disturbance >10 % of
full scale
80 MHz – 450 MHz ≥500 mV/d 100, 200 mV/div 2, 5, 10, 20, 50 mV/div
450 MHz – 1 GHz All ranges
1.4 GHz – 2 GHz All ranges
2 GHz – 2.7 GHz (1 V/m) All Ranges
