Fluke 190-062, -102, -104, -202, -204,-502, -504
Service Manual
3-4
Final Assembly Parts
See Table 3-1 and Figure 3-1, 3-2, and 3-3 for the Final Assembly parts.
Caution
The Test Tool contains a Li-ion battery. Do not mix with the
solid waste stream. Spent batteries should be disposed of by a
qualified recycler or hazardous materials handler.
Table 3-1. Final Assembly Parts and Kits
Part or Kit Ordering Code Consists of Following Parts Figure/Item nr
Case Set 4 channel 3981815
Front case (excluding lens/decal) 4
channel
3-3 / 5
Dust seal long (2x) 3-3 / 3
Dust seal short (2x) 3-3 / 4
Case seal 3-3 / 13
Bottom case assy 3-1 / 3
Battery door 3-1 / 14
Quarter turn screw (2x) 3-1 / 15
Adhesive foam (for battery door) --
Standup bracket 3-1 / 16
Case Set 2 channel 4035349
Front case (Excl. lens/decal) 2
channel
3-3 / 5
Dustseal long (2x) 3-3 / 3
Dustseal short (2x) 3-3 / 4
Case seal 3-3 / 13
Bottom case assy 3-1 / 3
Battery door 3-1 / 14
Quarter turn screw (2x) 3-1 / 15
Adhesive foam (for battery door) --
Standup bracket 3-1 / 16
Quarter turn screw 948609 For battery door (1x) 3-1 / 15
Li-ion Battery Pack BP290 26 Wh, 10.8 V ---
Li-ion Battery Pack BP291 52 Wh, 10.8 V ---
Lens/decal 190-062 4035360 --- 3-3 / 14
Lens/decal 190-102 4035372 --- 3-3 / 14
Lens/decal 190-104 3981826 --- 3-3 / 14
Lens/decal 190-202 4035324 --- 3-3 / 14
Lens/decal 190-204 3981832 --- 3-3 / 14
Lens/decal 190-502 4035385 3-3 / 14
Lens/decal 190-504 4534710 3-3 / 14
LCD assy Flk-190-II 3981844
LCD module
LCD fixation foam
Flat cable
3-3 / 1
3-3 / 2
3-3 / 3
Top holster (Input Cover
2 channels + meter)
4035397 --- 3-1 / 1
Top holster (Input Cover
4 channels)
3945328 --- 3-1 / 1
Sealing strip (flexible)
around inputs
3945319
Set of 2: 1 pce. for 4 channel + 1
pce. for 2 channel instruments
3-1 / 11
