Performance Verification
Scope Input A, B, C, D Tests 4
4-19
7. Continue through the test points.
8. When you are finished, set the 5502A to 0 (zero) Volt and Standby.
Table 4-7. Input A, B, C, D Frequency Measurement Accuracy Test
Model Time base 5502A-SC... MODE Voltage Frequency
Input A, B
Reading
All 20 ms/div wavegen, sine 600 mVpp 16 Hz 15.90 to 16.10
190-062 20 ns/div levsine 600 mVpp 60 MHz 59.68 to 60.32
190-104
190-102
20 ns/div levsine 600 mVpp 100 MHz 99.3 to 100.7
190-204
190-202
20 ns/div levsine 600 mVpp 200 MHz 198.8 to 201.2
190-502
190-504
20 ns/div levsine 600 mVpp 500 MHz 497.3 to 502.7
Note
Because Duty Cycle and Pulse Width measurements are
based on the same principles as Frequency measurements,
these measurement functions will not be verified separately.
Input A&B / C&D Phase Measurements Test
Note
The test steps for channel C and D are only for the models
190-104, 190-204, and 190-504.
Proceed as follows to test the phase measurement accuracy:
1. Connect the Test Tool to the 5502A as shown in Figure 4-5.
2. Select the Test Tool setup:
d) Recall the created setup (see Standard Test Tool Setup). Press
SAVE
,
F2
(RECALL) and select SETUP, press
ENTER
, select the setup name,
and press
ENTER
to recall the setup.
e) Press
SCOPE
.
f) Press
F2
(– READING …) and select with
F1
(– READINGS)
and
:
Reading 1, on A, Phase
Reading 2, on B, Phase
Reading 3, on C, Phase
Reading 4, on D, Phase
3. Use
mV
RANGE
and
RANGE
to select range 100 mV/div for A, B, C and D.
4. Use
TIMEsns
to select the required time base setting.
