Page #126 background imageLoading...
Page #126 background image
Calibration Adjustment
Final Calibration (Firmware: V10.9 and Lower) 5
5-41
Table 5-19. DMM Gain Calibration Points
Cal step UUT input value (5502A NORMAL)
CL 0840 500 mV
CL 0849 2.5 V
CL 0841 5 V
CL 0842 50 V (set 5502A to OPR!)
CL 0843 500 V
CL 0844 1000 V
Multimeter Numeric Zero
Note
The adjustment steps for the meter section are only for the models
190-062, 190-102, and 190-202.
To do the Multimeter (DMM) Zero calibration:
1. Press
F2
to select calibration adjustment step CL 0890.
2. Short circuit the banana jack Meter inputs properly (calibration includes
Ohms zero). Use a test lead as short as possible.
3. Press
F3
to start the zero calibration.
4. Wait until the display shows the status :READY.
5. Remove the input terminations.
6. Continue at the Multimeter (DMM) Ohm Gain section.
Multimeter Ohm Gain
Note
The adjustment steps for the meter section are only for the models
190-062, 190-102, and 190-202.
To do the DMM Ohm Gain calibration:
1. Press
F2
to select the first calibration adjustment step in Table 5-20.
2. Connect the Test Tool to the 5502A as shown in Figure 5-18. Notice that the
sense leads must be connected directly to the Test Tool.
