Performance Verification
Introduction 4
4-3
Introduction
Warning
To prevent possible electrical shock, fire, or personal injury, do
not service the Test Tool unless you are qualified to do so.
Service described in this manual is to be done only by qualified
service personnel.
Table 4-1 lists the available models for the Test Tools.
Table 4-1. Model Descriptions
Model Description of Main Features
190-062 Two 60 MHz Scope Inputs (BNC), one Meter Input (banana jacks).
190-102 Two 100 MHz Scope Inputs (BNC), one Meter Input (banana jacks).
190-104 Four 100 MHz Scope Inputs (BNC).
190-202 Two 200 MHz Scope Inputs (BNC), one Meter Input (banana jacks).
190-204 Four 200 MHz Scope Inputs (BNC).
190-502 Two 500 MHz Scope Inputs (BNC), one Meter Input (banana jacks).
190-504 Four 500 MHz Scope Inputs (BNC).
The Test Tool should be calibrated and in operating condition on arrival.
The following performance tests are provided to ensure that the Test Tool is in
proper operating condition. If the Test Tool fails any of the performance tests,
calibration adjustment (see Chapter 5) and/or repair is necessary.
The Performance Verification Procedure is based on the specification (see
Chapter 2). The values given here are valid for ambient temperatures between
18 °C and 28 °C.
The Performance Verification Procedure is a quick and efficient way to check all
main specifications of the Test Tool. Accuracy of Test Tool specifications not
tested is linked to those tested in this verification procedure and is embedded in
the Test Tool’s software. This link is tested extensively for each new software
release.
