Calibration Adjustment
Final Calibration For v11.10 and later 5
5-27
5. Press
F3
to start the calibration.
6. Wait until the display shows the calibration status
:READY.
7. Press
F2
to select the next calibration step, set the 5502A to the next
calibration point, and start the calibration. Continue through all calibration
points.
8. When you are finished, set the 5502A to Standby.
9. Continue at the Save Calibration Data and Exit section.
Table 5-8. Ohm Gain Calibration Points
Cal Step UUT input Value (5500 NORMAL)
CL 0910 100 Ω
CL 0911 1 kΩ
CL 0912 10 kΩ
CL 0913 100 kΩ
CL 0914 1 MΩ
CL 0915 10 MΩ
