Fluke ScopeMeter 190 II Series Service Manual

Fluke 190-062, -102, -104, -202, -204, -502, -504
Service Manual
5-32
Table 5-11. Input B LF-HF Gain Calibration Points
Cal step UUT input signal 5502A Setting
CL 0674 0.5 Vpp square wave, 1 kHz SCOPE edge, 0.5 Vpp, 1 kHz
CL 0482 0.62 Vpp sine wave, 50 kHz SCOPE levsine, 0.62 Vpp, 50 kHz
CL 0483 0.62 Vpp sine wave
Fluke 190-202/204: 221 MHz
Fluke 190-102: 151 MHz
Fluke 190-104: 121 MHz
Fluke 190-062: 81 MHz
SCOPE levsine, 0.62 Vpp,
221 MHz
151 MHz
121 MHz
81 MHz
Table 5-12. Input B LF-HF Gain Calibration Points (Extra steps for 190-104/204, V10.4x firmware *)
Cal step UUT input signal 5502A Setting
CL 0462 124 mVpp sine wave, 50 kHz SCOPE levsine, 124 mVpp, 50 kHz
CL 0463 124 mVpp sine wave
Fluke 190-204: 221 MHz
Fluke 190-104: 121 MHz
SCOPE levsine, 124 mVpp,
221 MHz
121 MHz
* Four channel instruments (190-104/204) with firmware V10.4x require the extra steps CL 462 and CL 463. Installed
firmware version can be checked via key sequence: USER key, F3 – VERSION & CAL, Software Version: …
