Fluke ScopeMeter 190 II Series Service Manual

Fluke 190-062, -102, -104, -202, -204, -502, -504
Service Manual
5-34
Table 5-13. Input C LF-HF Gain Calibration Points
Cal step UUT input signal 5502A Setting
CL 0656 0.5 Vpp square wave, 1 kHz SCOPE edge, 0.5 Vpp, 1 kHz
CL 0484 0.62 Vpp sine wave, 50 kHz SCOPE levsine, 0.62 Vpp, 50 kHz
CL 0485 0.62 Vpp sine wave
Fluke 190-204: 221 MHz
Fluke 190-104: 121 MHz
SCOPE levsine, 0.62 Vpp,
221 MHz
121 MHz
Table 5-14. Input C LF-HF Gain Calibration Points (Extra steps for 190-104/204, V10.4x firmware *)
Cal step UUT input signal 5502A Setting
CL 0464 124 mVpp sine wave, 50 kHz SCOPE levsine, 124 mVpp, 50 kHz
CL 0465 124 mVpp sine wave
Fluke 190-204: 221 MHz
Fluke 190-104: 121 MHz
SCOPE levsine, 124 mVpp,
221 MHz
121 MHz
* Four channel instruments (190-104/204) with firmware V10.4x require the extra steps CL 464 and CL 465. Installed
firmware version can be checked via key sequence: USER key, F3 – VERSION & CAL, Software Version: …
