Fluke ScopeMeter 190 II Series Service Manual

Fluke 190-062, -102, -104, -202, -204, -502, -504
Service Manual
2-4
Horizontal
Minimum Time Base Speed
(Scope Record) ....................................................... 2 min/div
Real Time Sampling Rate
Fluke 190-50x:
5 ns to 4 μs/div (3 or 4 channels).................... up to 1.25 GS/s
2 ns to 4 μs/div (2 channels) ........................... up to 2.5 GS/s
1 ns to 4 μs/div (1 channel) ............................. up to 5 GS/s
10 μs to 120 s/div ............................................ 125 MS/s
Fluke 190-202, -204:
2 ns to 4 μs/div (1 or 2 channels).................... up to 2.5 GS/s
5 ns to 4 μs/div (3 or 4 channels).................... up to 1.25 GS/s
10 μs to 120 s/div ............................................ 125 MS/s
Fluke 190-102, -104:
5 ns to 4 μs/div (all channels) ......................... up to 1.25 GS/s
10 μs to 120 s/div ............................................ 125 MS/s
Fluke 190-062:
10 ns to 4 μs/div (all channels) ....................... up to 625 MS/s
10 μs to 120 s/div ............................................ 125 MS/s
Glitch Detection
4 μs to 120 s/div .................................................. displays glitches as fast as 8 ns
Waveform Display ................................................... A, B, C, D, Math (+, -, x, X-Y mode, spectrum) Normal, Average,
Persistence, Reference
Time Base Accuracy ............................................... ±(100 ppm + 0.04 div)
Record Length (all models): see table that follows.
Record Length (all models, Samples/points per input)
Mode Glitch Detect On Glitch Detect Off Max. Sample Rate
Scope - Normal 300 min/max pairs 3 k true samples compressed
into 1 screen (300 samples per
screen)
190-062: 625 MS/s
190-102/104: 1.25 GS/s
190-202/204: 2.5 GS/s (1 or 2 channels on)
190-204: 1.25 GS/s (3 or 4 channels on)
190-50x: 5 GS/s (1 channel on)
190-50x: 2.5 GS/s (2 channels on)
190-504: 1.25 GS/s (3 or 4 channels on)
Scope - Fast 300 min/max pairs -
Scope - Full 300 min/max pairs 10 k true samples, compressed
into 1 screen.
Use Zoom and Scroll to see
waveform details
Scope Record Roll 30 k samples 4x 125 MS/s
Trend Plot >18 k min/max/average
values/measurement
Up to 5 measurements/second
Trigger and Delay
Trigger Modes ......................................................... Automatic, Edge, Video, Pulse Width, N-Cycle, External (190-xx2)
Trigger Delay .......................................................... up to +1200 divisions
Pre-Trigger View ..................................................... one full screen length
Delay ....................................................................... -12 div to +1200 div
Max. Delay .............................................................. 48 s at 4 s/div
Automatic Connect-and-View Trigger
Source ..................................................................... A, B, C, D
EXT (190-xx2)
Slope ....................................................................... Positive, Negative, Dual
