Fluke ScopeMeter 190 II Series Service Manual

Fluke 190-062, -102, -104, -202, -204, -502, -504
Service Manual
4-6
3. Press
F3
to change the PROBE B setting.
4. Select
Probe Type: Voltage | Attenuation: 1:1.
5. Press
C
: INPUT C ON.
6. Press
F3
to change the PROBE C setting.
7. Select
Probe Type: Voltage | Attenuation: 1:1.
8. Press
D
: INPUT D ON.
9. Press
F3
to change the PROBE D setting.
10. Select
Probe Type: Voltage | Attenuation: 1:1.
11. Press
A
. The inverse text indicates the actual settings.
12. Press
F3
to change the PROBE A setting.
13. Select
Probe Type: Voltage | Attenuation: 1:1.
14. Press
SCOPE
.
15. Press
F1
– READINGS ON.
16. Press
F2
– READING … and select with
F1
– READINGS and with
:
a) Reading 1, on A, V dc
b) Reading 2, on B, V dc
c) Reading 3, on C, V dc
d) Reading 4, on D, V dc
17. Press
F4
WAVEFORM OPTIONS and select
Glitch: Off | Acquisition: Normal | Average: Off | Waveform: Normal.
18. Press
MANUAL
AUTO
to select MANUAL ranging (MANUAL in upper right of display).
19. Press
A
. Use
MOVE
and
MOVE
to move the Input A ground level (indicated
by the zero icon
in the left margin) to the center grid line. Do this for all
channels.
20. Press
SAVE
.
21. Press
F1
SAVE...
22. Use
to select SCREEN+SETUP.
23. Press
ENTER
.
24. Use
to select OK SAVE. Remember the name under which the
settings are saved (for instance SCOPE 1).
25. Press
ENTER
to save the settings.
26. Press
HOLD
RUN
to leave the Hold mode.
