Fluke ScopeMeter 190 II Series Service Manual

Performance Verification
Scope Input A, B, C, D Tests 4
4-15
5. Use
TIMEsns
to change the time base and lock on 20 μs/div for the 20 kHz
signal and on 10 ms/div for the 60 Hz signal.
6. Use
mV
RANGE
and
V
RANGE
to select the manual vertical ranging. Set the input A and
B sensitivity range to the first test point in Table 4-4.
The sensitivity ranges are indicated in the lower display edge.
7. Set the 5502A to source the appropriate ac voltage.
8. Observe readings
A, B, C, and D and check to see if they are within the range
shown under the appropriate column.
9. Continue through the test points.
10. When you are finished, set the 5502A to 0 (zero) Volt and Standby.
Table 4-4. Volts AC Measurement Verification Points
Range
5502A output
2 Ch Input Reading 4 Ch Input Reading
V ac Frequency
2 mV/div (Select 10 ms/div) 4 mV 60 Hz 2.9 mV to 5.1 mV 2.9 mV to 5.1 mV
Note
Set input A, B, Bandwidth 10 kHz or 20 kHz to prevent OL due
to calibrator noise, see step 2.
5 mV/div 10 mV 60 Hz 8.8 mV to 11.2 mV 8.7 mV to 11.3 mV
10 mV/div (Select 20 μs/div). 20 mV 20 kHz 18.0 mV to 22.0 mV 17.7 mV to 22.3 mV
Note
Set input A, B Bandwidth 20 MHz.
20 mV/div 40 mV 20 kHz 37.5 mV to 42.5 mV 36.9 mV to 43.1 mV
50 mV/div 100 mV 20 kHz 96.0 mV to 104.0 mV 94.5 mV to 105.5 mV
100 mV/div 200 mV 20 kHz 180 mV to 220 mV 177 mV to 223 mV
200 mV/div 400 mV 20 kHz 375 mV to 425 mV 369 mV to 431 mV
500 mV/div (Select 10 ms/div) 900 mV 60 Hz 876 mV to 924 mV 863 mV to 937 mV
500 mV/div (Select 20 μs/div) 900 mV 20 kHz 862 mV to 938 mV 849 mV to 951 mV
1 V/div 2 V 20 kHz 1.80 V to 2.20 V 1.77 V to 2.23 V
2 V/div 4 V 20 kHz 3.75 V to 4.25 V 3.69 V to 4.31 V
5 V/div 9 V 20 kHz 8.62 V to 9.38 V 8.49 V to 9.51 V
10 V/div 20 V 20 kHz 18.0 V to 22.0 V 17.7 V to 22.3 V
20 V/div 40 V 20 kHz 37.5 V to 42.5 V 36.9 V to 43.1 V
50 V/div 90 V 20 kHz 86.2 V to 93.8 V 84.9 V to 95.1 V
100 V/div 200 V 20 kHz 180 V to 220 V 177 V to 223 V
