Fluke ScopeMeter 190 II Series Service Manual

Calibration Adjustment
Final Calibration For v11.10 and later 5
5-13
Table 5-1. Input A LF-HF Gain Calibration Points
Cal step UUT input signal 5502A Setting
CL 0654 0.5 Vpp square wave, 1 kHz SCOPE edge, 0.5 Vpp, 1 kHz
CL 0415 100 mVpp square wave, 1 kHz SCOPE edge, 100 mVpp, 1 kHz
CL 0510 2.5 Vpp square wave, 1 kHz SCOPE edge, 2.5 Vpp, 1 kHz
CL 0580 2.5 Vpp sine wave, 50 kHz SCOPE levsine, 2.5 Vpp, 50 kHz
CL 0581 2.5 Vpp sine wave
Red subversion 5; Blue Subversion 2
Fluke 190-502/504: 501 MHz
Fluke 190-202/204: 381 MHz
Fluke 190-102/104: 151 MHz
Fluke 190-062: 111 MHz
SCOPE levsine, 2.5 Vpp,
501 MHz
381 MHz
151 MHz
111 MHz
CL 0480 500 mVpp sine wave, 50 kHz SCOPE levsine, 500 mVpp, 50 kHz
CL 0481 0.5 Vpp sine wave
Red subversion 5; Blue Subversion 2
Fluke 190-502/504: 501 MHz
Fluke 190-202/204: 381 MHz
Fluke 190-102/104: 151 MHz
Fluke 190-062: 111 MHz
Fluke 190-202/204: 221 MHz
Fluke 190-102/104: 141 MHz
Fluke 190-062: 91 MHz
SCOPE levsine, 0.5 Vpp,
501 MHz
381 MHz
151 MHz
111 MHz
221 MHz
141 MHz
91 MHz
CL 0460 100 mVpp sine wave, 50 kHz SCOPE levsine, 100 mVpp, 50 kHz
CL 0461 100 mVpp sine wave
Red subversion 5; Blue Subversion 2
Fluke 190-502/504: 501 MHz
Fluke 190-202/204: 381 MHz
Fluke 190-102/104: 151 MHz
Fluke 190-062: 111 MHz
Fluke 190-202/204: 221 MHz
Fluke 190-102/104: 141 MHz
Fluke 190-062: 91 MHz
SCOPE levsine, 100 mVpp,
501 MHz
381 MHz
151 MHz
111 MHz
221 MHz
141 MHz
91 MHz
