FOR-A MFR-5000 User Manual

143
10-1-6. MFR-18RU
Buttons/Colors
18 buttons (3 colors: red/green/orange), user assignable
LCD display x 18 (Max. 7 characters x 2 lines, Displayed above each
button) with Rotary selector
Number of
Connection
Max. 128 (including Main, Remote and GPI units)
Interfaces
MFR-LAN
10/100BASE-TX RJ-45 x 1
(For connection to MU. A network hub required for multiple unit
configuration.)
SERVICE
RS-232C 9-pin D-sub (male) x 1 (for maintenance)
Temperature
0°C to 40°C
Humidity
30% to 85% (no condensation)
Power
+12 V DC Pin-connector x 2 (redundant power supply as standard)
Consumption
100 V AC to 120 V AC: 12 VA (6 W),
200 V AC to 240 V AC: 18 VA (8 W)
Dimensions
430(W) x 44(H) x 42(D) mm EIA 1 RU
Weight
2 kg
Consumables
AC adaptor: Replace every 5 years.
10-1-7. MFR-16RU/16RUD
Buttons/Color
16 buttons (1 color: green), user assignable
Menu Display (Max. 16 characters x 2 lines) (MFR-16RUD only)
Number of
Connection
Max. 128 (including Main, Remote and GPI units)
Interfaces
MFR-LAN
10/100BASE-TX RJ-45 x 1
(For connection to MU. A network hub required for multiple unit
configuration.)
Temperature
0°C to 40°C
Humidity
30% to 85% (no condensation)
Power
+12 V DC Pin-connector x 1
Consumption
MFR-16RU: 100 V AC to 120 V AC: 7 VA (3 W),
200 V AC to 240 V AC: 11 VA (4 W)
MFR-16RUD: 100 V AC to 120 V AC: 8 VA (3 W),
200 V AC to 240 V AC: 11 VA (4 W)
Dimensions
430(W) x 44(H) x 34 (D) mm EIA 1 RU
Weight
1 kg
Consumables
AC adaptor: Replace every 5 years.
