FOR-A MFR-5000 - Mfr-18 Ru; Mfr-16 Ru

150
10-2-6. MFR-18RU
(All dimensions in mm.)
* The panel buttons can be fitted within the rack by sliding the rack ears forward to attach as
shown in the bottom figure above.
10-2-7. MFR-16RU
(All dimensions in mm.)
DC12V IN
2 1
SERVICE
2.3
12 20 12
28 9
POWER
BUSY SETUP
LOCK R ESET
430
462
480
MFR-18RU
REMOTE CONTROL UNIT
6 32 6
44
POWER
BUSY SETUP
LOCK R ESET
430
462
480
MFR-18RU
REMOTE CONTROL UNIT
9
50
6 32 6
44
42
MFR-LAN
PA G E A
(HOLD 3SE C)
PA G E B
LOCK RESE T
POW ER
BUSY SETUP
LO CK DE ST
(HOLD 3SE C)
LO CK PAN L
A B
430
462
480
44 32 6
6
6.4
REMOT E CONTROL UNIT
M FR-16R U
34
DC12V IN
MFR-LAN
