2-1-1. Matrix Size Chart
 Standard SDI Signal Routing
Matrix size varies depending on the number of installed MFR-16SDI/16SDIA and
MFR-16SDO cards as shown below. (128 x 128 to 16 x 16)
Number of cards: MFR-16SDO
8
7
6
5
4
3
2
1
Number of
cards:
MFR-16SDI/
16SDIA
8
128 x 128
128 x 112
128 x 96
128 x 80
128 x 64
128 x 48
128 x 32
128 x 16
7
112 x 128
112 x 112
112 x 96
112 x 80
112 x 64
112 x 48
112 x 32
112 x 16
6
96 x 128
96 x 112
96 x 96
96 x 80
96 x 64
96 x 48
96 x 32
96 x 16
5
80 x 128
80 x 112
80 x 96
80 x 80
80 x 64
80 x 48
80 x 32
80 x 16
4
64 x 128
64 x 112
64 x 96
64 x 80
64 x 64
64 x 48
64 x 32
64 x 16
3
48 x 128
48 x 112
48 x 96
48 x 80
48 x 64
48 x 48
48 x 32
48 x 16
2
32 x 128
32 x 112
32 x 96
32 x 80
32 x 64
32 x 48
32 x 32
32 x 16
1
16 x 128
16 x 112
16 x 96
16 x 80
16 x 64
16 x 48
16 x 32
16 x 16
 AUDIO Signal Routing
Matrix size varies depending on the number of installed MFR-16ADI, MFR-16AAI and
MFR-16ADAO cards as shown below. (1 stereo pair = 2 channels)
Number of cards: MFR-16ADAO
8
7
6
5
4
3
2
1
Number of
cards:
MFR-16ADI
or
16AAI
4
64 x 64
64 x 56
64 x 48
64 x 40
64 x 32
64 x 24
64 x 16
64 x 8
3
48 x 64
48 x 56
48 x 48
48 x 40
48 x 32
48 x 24
48 x 16
48 x 8
2
32 x 64
32 x 56
32 x 48
32 x 40
32 x 32
32 x 24
32 x 16
32 x 8
1
16 x 64
16 x 56
16 x 48
16 x 40
16 x 32
16 x 24
16 x 16
16 x 8
Matrix size varies depending on the number of installed MFR-16AESI, MFR-16AESO,
MFR-16AAIEX and MFR-16AAOEX cards as shown below. (1 stereo pair = 2 channels)
* Up to 4 cards for MFR-16AAIEX and MFR-16AAOEX cards
Number of cards: MFR-16AESO or 16AAOEX
8
7
6
5
4
3
2
1
Number of
cards:
MFR-
16AESI
or
16AAIEX
8
128 x 128
128 x 112
128 x 96
128 x 80
128 x 64
128 x 48
128 x 32
128 x 16
7
112 x 128
112 x 112
112 x 96
112 x 80
112 x 64
112 x 48
112 x 32
112 x 16
6
96 x 128
96 x 112
96 x 96
96 x 80
96 x 64
96 x 48
96 x 32
96 x 16
5
80 x 128
80 x 112
80 x 96
80 x 80
80 x 64
80 x 48
80 x 32
80 x 16
4
64 x 128
64 x 112
64 x 96
64 x 80
64 x 64
64 x 48
64 x 32
64 x 16
3
48 x 128
48 x 112
48 x 96
48 x 80
48 x 64
48 x 48
48 x 32
48 x 16
2
32 x 128
32 x 112
32 x 96
32 x 80
32 x 64
32 x 48
32 x 32
32 x 16
1
16 x 128
16 x 112
16 x 96
16 x 80
16 x 64
16 x 48
16 x 32
16 x 16
► See section 2-4. "Audio Input / Output Cards" for details on audio input and output cards.
 RS-422 Data Routing
Matrix size can be freely selected depending on the number of installed MFR-16DTIO cards,
regardless of their slot location, as shown below.
Number of
MFR-16DTIO
cards
8
7
6
5
4
3
2
1
Number of
RS-422 ports
128
112
96
80
64
48
32
16
Routing
Matrix size can be freely selected depending on the number of installed MFR-16DTIO
cards, regardless of their slot location.
RS-422 data can be routed between ports in the same card or different cards.
See section 2-5. “RS-422 Data Input / Output Cards” for details on input and output port
settings.
