FOR-A MFR-5000 - MFR-16 ADI (AES Input with SRC)

30
Channels 17 to 24
Pin No.
Setting
Pin No.
Setting
13
CH17 +
25
CH17 COM
12
CH17 -
24
CH18 +
11
CH18 COM
23
CH18 -
10
CH19 +
22
CH19 COM
9
CH19 -
21
CH20 +
8
CH20 COM
20
CH20 -
7
CH21 +
19
CH21 COM
6
CH21 -
18
CH22 +
5
CH22 COM
17
CH22 -
4
CH23 +
16
CH23 COM
3
CH23 -
15
CH24 +
2
CH24 COM
14
CH24 -
1
SG
-
-
Channels 25 to 32
Pin No.
Setting
Pin No.
Setting
13
CH25 +
25
CH25 COM
12
CH25 -
24
CH26 +
11
CH26 COM
23
CH26 -
10
CH27 +
22
CH27 COM
9
CH27 -
21
CH28 +
8
CH28 COM
20
CH28 -
7
CH29 +
19
CH29 COM
6
CH29 -
18
CH30 +
5
CH30 COM
17
CH30 -
4
CH31 +
16
CH31 COM
3
CH31 -
15
CH32 +
2
CH32 COM
14
CH32 -
1
SG
-
-
2-4-3. MFR-16ADI (AES Input with SRC)
MFR-16ADI is an AES/EBU audio input card with SRC.
Up to 4 cards can be installed into Slot No. 05 to 08.
► See section 2-1-1. "Matrix Size Chart."
BNC x 16 inputs (16 stereo pairs, 32 channels), unbalanced, 75 Ohm
IMPORTANT
When using an MFR-16ADI, a Black Burst signal should be input to REF IN2.
To output the MFR-16ADI digital audio input, use MFR-16ADAO. The
MFR-16AESO/16AAOEX cannot output MFR-16ADI audio channels.
 SRC (Sample Rate Converter)
A Sample Rate Converter is implemented in MFR-16ADI cards.
It allows you to accept audio signals of the following frequencies:
32 kHz, 44.1 kHz, 48 kHz and 96 kHz
19/20
21/22 29/30 27/28 25/26 23/24
17/18 15/16 13/14 11/12
9/10
7/8 5/6 3/4
31/32
1/2
ADI
(No.)
