FOR-A MFR-5000 - Page 38

38
No.
Item
Description
A
POWER
Displays the power status.
► See the table on the next page for details on indications.
B
BUSY
Displays the flash memory writing status of backup settings.
► See the table on the next page for details on indications.
C
LOCK
Displays the LOCK status.
► See the table on the next page for details on indications.
► See section 6-3. "Lock" for details on the lock function.
D
SETUP
Used for IP address or other settings.
► See section 5-6. "Setup Menu." for details on the SETUP menu.
E
RESET
Used to re-initialize the remote control panel.
F
Buttons
All buttons are user assignable.
(1) 7-color selectable button name indication (red, green, yellow,
blue, white, cyan or magenta) (hereafter called LCD)
(2) 3-color selectable button illumination (red, green or orange)
(3) Green illumination
G
NAME DISPLAY
7-color selectable button name/assignment indications (red, green,
yellow, blue, white, cyan or magenta)
H
MENU
Displays setting menus and status.
I
CONTROL
Used to enter menu settings.
J
CANCEL
Used to cancel menu settings.
K
PAGE A /
LOCK PANL
Page switch button.
Pressing the button switches Page 1 and Page 2 of Group A.
The button is unlit if Page 1 is applied.
The button is lit orange if Page 2 is applied.
To use the button as LOCK LOCAL, press and hold down (within 3
seconds). (*)
L
PAGE B /
LOCK DEST
Page switch button.
Pressing the button switches Page 1 and Page 2 of Group B.
The button is unlit if Page 1 is applied.
The button is lit orange if Page 2 is applied.
To use the button as LOCK ALL, press and hold down (within 3
seconds). (*)
M
Display
Displays crosspoints and button assignments.
N
↑
UP / DOWN buttons, used to select items to be viewed on the
Display.
O
↓
P
ENTER
Used to confirm settings on the Display.
Q
FUNCTION
Function assignable buttons. (Green illumination)
R
PAGE A
If enabled, Group A pages can be controlled.
S
PAGE B
If enabled, Group B pages can be controlled.
T
LOCK
Lock function assignable button
U
Current DEST
button
Displays the current destination channel.
V
Current SRC
button
Displays the current source channel.
W
Current PAGE
display
Displays the current page.
(*) PAGE Switch and LOCK features are initially enabled and can be disabled in the [Web-based Control:
Assign Function page], respectively.
