78
Parameter
Description
Lock
Selects Lock mode for each Gearbox pair between Line Lock and Genlock.
When Genlock is selected, the external reference signal input to the MFR
Main unit is used.
Delay (H)
Selects the H delay amount for each Gearbox pair.
The following input format conversions are available on MFR-8SDIGB / 16SDIGB cards
From
To
Lock
Delay(H)
(*3)
Total Delay
(*4)
Ancillary Data
12G-SDI
3G Quad (2SI)
Line lock
(*1)
0.3H to 1H
0 frame + ** (H)
Through
Mask
Genlock
0.3H to 1H
0 frame + ** (H)
1 frame + 0H
1 frame + Delay (H)
0.5H to 1H
1 frame + 0H
12G-SDI
3G Quad (SQD)
Line lock
(*1)(*2)
Genlock
0.3H to 1H
1 frame + Delay (H)
3G Quad (2SI)
3G Quad (SQD)
3G Quad (SQD)
3G Quad (2SI)
0.5H to 1H
1 frame + 0H
The following output format conversions are available on MFR-8SDOGB / 16SDOGB cards
From
To
Lock
Delay(H)
(*3)
Total Delay
(*4)
Ancillary Data
3G Quad (2SI)
12G-SDI
Line lock
(*1)
0.3H to 1H
0 frame + ** (H)
Through
Mask
Genlock
0.3H to 1H
0 frame + ** (H)
1 frame + Delay (H)
0.5H to 1H
1 frame + 0H
3G Quad (SQD)
12G-SDI
Line lock
(*1)(*2)
Genlock
0.3H to 1H
1 frame + Delay (H)
3G Quad (2SI)
3G Quad (SQD)
3G Quad (SQD)
3G Quad (2SI)
0.5H to 1H
1 frame + 0H
(*1)
SDI signal input to the A (MFR-5000) or D connector (MFR-3000/8000) is used as reference.
When Line Lock is selected on MFR-16SDOGB cards, video signals are synchronized by inputting
signals to all four channels in Gearboxes.
(*2)
Available only on Gearbox 1 and 3 for MFR-5000 and Gearbox 2 and 4 for MFR-3000/8000
(*3)
Delay (H) and Total Delay (H) indicate amount of delay and their settings correspond to the following
adjustable ranges.
Delay (H) setting
Adjustable range
Delay (H) setting
Adjustable range
0.3H
-0.8H to +0.2H
0.8H
-0.3H to +0.7H
0.4H
-0.7H to +0.3H
0.9H
-0.2H to +0.8H
0.5H
-0.6H to +0.4H
1H (1)
-0.1H to +0.9H
0.6H
-0.5H to +0.5H
1H (2)
-0.5H to +0.5H
0.7H
-0.4H to +0.6H
(*4)
If Total Delay (frame) is set to “0 frame” for both gearboxes, the different Total Delay (H) setting is
available for both Gearboxes.
If Total Delay (frame) is set to “1 frame” for either one or both Gearboxes, the same Total Delay (H)
setting is required for both Gearboxes: 1 frame + 0H or 1frame + Delay (H).
