FOR-A MFR Series User Manual

30
4-1-9-5. Switcher Input Channel (MFR-3000/5000/8000 only)
Input channels in the switcher (HVS-100/110/390HS/2000/6000) can be remotely controlled
by assigning them to MFR logical sources.
Select HVS-390HS in the Device Select page to display the page as shown below, in which
switcher source signals can be assigned to MFR logical sources. The page shown as below is
an MFR-5000 page.
Set the following parameters.
Parameter
Description
Alternative Source
Allows you to select an Alternative source.
If the switcher selects sources that are not assigned to MFR
channels, they are replaced with the Alternative Source in the MFR.
Table Name
Allows you to set the table name in which assignments are saved.
Unit
Select HVS-390HS.
Level
Allows you to select a level.
ID
Allows you to select a unit ID (4
th
octet of the switcher IP address).
(MFR-5000/8000 only)
Page
Allows you to move between pages.
Logical No. / Name
Allows you to select a Logical input channel.
Switcher Channel
Allows you to select a Switcher Channel input.
