Fraco SEP-5000 - Overview, Double-Mast - Twin Units; Figure 2 - Double-Mast Assembly, Twin Units; Table 6 - Double-Mast Assembly Components, Twin Units

Transport platform SEP Serie
SEP user’s manual Page 17 of 89 Doc no. RD-7243-MA-001-02
Figure 2 – Double-mast assembly, twin units
4.4.2. Overview, double-mast – twin units
N°
Item
Description
1
RD-7243-AT-100
Cable guide
2
RD-7243-BC-103
Platform left SEP-5000
3
RD-7243-BC-104
Platform right SEP-5000
4
RD-7243-BE-107
Ground cabinet GC1 SEP
5
RD-7243-GS-113
Ground enclosure – twin mast
6
RD-7243-ME-100
Electric cable barrel SEP
7
13090137
Mast section 26" x 26" x 5' 0", 2 racks (Mast climber)
8
Depending on
model and
technical
specifications
Ground base assembly
9
Depending on
model and
technical
specifications
Mast tie assembly and mast anchor system
Table 6 - Double-mast assembly components, twin units
Double mast section
(13090137)
3
2
1
4
5
6
7
8
9
