Transport platform SEP Serie
SEP user’s manual Page 80 of 89 Doc no. RD-7243-MA-001-02
12.3. Mast section technical sheet
Mast section 26" x 26" x 5'-0", 1 rack (13090104)
Imperial
Metric
A
Length
28-5/8"
727 mm
B
Width
29-7/8"
760 mm
C
Height
5'-0"
1,5 m
Weight
300 lb
136 kg
Table 14 – Mast section weight and dimensions
Figure 50 – Mast section dimensions
A
B
C
