Transport platform SEP Serie
SEP user’s manual Page 46 of 89 Doc no. RD-7243-MA-001-02
Figure 27 – Drop test remote control
7.7.4. Drop test remote control
N°
Description
1
Three (3) position selector (DESCEND / ARRÊT / MONTER)
2
Drop test button
3
Black button (ACTIVÉ / ENABLE)
3
2
1
∞ SEE SECTION 10.1 DROP TEST PROCEDURE, ON PAGE 75.
