Fraco SEP-5000 - Table 7 - General Dimensions

Transport platform SEP Serie
SEP user’s manual Page 20 of 89 Doc no. RD-7243-MA-001-02
Description
Values
A
MAXIMUM height of first (1)
mast anchor
20’-0” (6,0 m)
B
MAXIMUM height of second
(2) mast anchor
« REFER TO TABLE 2 – GENERAL DATA (TYPICAL SPACING BETWEEN ANCHORS), ON
PAGE 14 »
C
Typical spacing between
anchors
« REFER TO TABLE 2 – GENERAL DATA (TYPICAL SPACING BETWEEN ANCHORS), ON
PAGE 14 »
D
MAXIMUM height of the
installation
1 300’-0” (400 m)
E
MAXIMUM floor height
17-9/16” (450 mm)
F
MAXIMUM height over the
last (highest) anchor
Ŧ At installation: 0ft (0m) MAX above the roof of the platform to the last anchor
(position of anchor to install).
ŦŦ In operation: 0ft (0m) MAX from the floor of the platform to the last anchor.
G
Spacing between anchors
MIN 29” MAX 50”
(0,73 m) (1,27m)
SEE TABLE 11 - DIMENSIONS AND ANCHOR FORCES DISTRIBUTION, ON PAGE 36.
H
Distance between center of
the mast and face of
anchoring wall (length of
mast anchoring)
MIN 64,5” MAX 110”
(1,65 m) (2,8 m)
SEE TABLE 11 - DIMENSIONS AND ANCHOR FORCES DISTRIBUTION, ON PAGE 36.
*
J
Spacing between the
platform and the ground
protection mesh
* MIN 18” MAX 80”
(0,45 mm) (2,0 m)
**
K
Height of the ground
protection mesh
** LOW MESH ** FULL HEIGHT
MIN 43” (1,10 m) MIN 6’-6” (2,0m)
MAX moins de 6’-6” (2,0m) .
***
L
Height of ground level door
*** LOW MESH *** FULL HEIGHT
MIN 43” (1,10 m) MIN 6’-6” (2,0 m)
MAX 3’-11 1/4” (1,20m) .
M
Height and spacing of cable
guides
MAX 20'-0”
(6,0 m)
N
Clearance between platform
and power lines
Refer to effective local regulation
P
Distance between highest
anchor and end of mast
MIN 15'-3 5/8” (4,66 m)
Table 7 – General dimensions
* The MIN value 18" (0,45 m) may be reduced if "K" the height of the mesh is greater than 6'-6" (2,0 m).
** Consider restrictions on the use of a low mesh.
*** Consider restrictions on the use of a low mesh.
Ŧ Reference height during installation (assembly/disassembly).
ŦŦ Reference height during operation (in use).
