Transport platform SEP Serie
SEP user’s manual Page 44 of 89 Doc no. RD-7243-MA-001-02
The control box may be
installed on the left or on the
right depending on the platform
model
Figure 25 – Control box (CC2)
7.7.2. Operator control box (CC2)
N°
Description
1
EMERGENCY STOP button
2
White light button HAUT / UP
3
White light button BAS / DOWN
4
Blue light button PROCHAIN ÉTAGE – ARRÊT / NEXT
FLOOR - STOP
5
Yellow light button DÉBARRER PORTE / UNLOCK
DOOR
1
2
3
4
5
